    Implant malposition: A new, easy-to-use radiographic aid for prevention

    Nov. 6, 2023
    The most common complication leading to failed dental implants arises from poor positioning of the implant fixture at the time of placement. Learn how the Sniper X-Ray System can assure accurate placement.
    Scott Froum, DDS
    6549536a6aa606001ede142a Primarysolutionimplantmalposition

    There are many reasons why dental implants ail or fail, with the most common complication arising from poor positioning of the dental implant fixture at the time of placement.1 Various surgical methods and techniques have been developed to try to correct implant malposition during surgery. In addition, there are many methods both restoring dentists and dental laboratories use to correct misplaced implants to give proper tooth anatomy and emergence profile.2

    Although restorative and laboratory correction is possible, the best method continues to be prevention—i.e., placing the dental implant in the proper position at the time of surgery.3 Many clinicians still use freehand placement for single- and multiple-unit implant placement, and even with guided surgery, care must be taken when using information from perioperative radiographs to guide the surgical procedure. When taking guide pin radiographs during implant surgery, if the x-ray tube is not perpendicular to the radiographic film/sensor and the depth gauge, distortion of the image may occur (figure 1). This is especially important in a patient with limited opening and at the corners of the mouth in the canine area as there is a higher potential in these areas for alignment error.

    Figure 1: X-ray alignment distortion
    Figure 1: X-ray alignment distortion

    The Sniper X-Ray System is a simple device designed to ensure orthogonal x-ray beam alignment and correct osteotomy guide pin positioning so as not to provide false information to the implant surgeon during implant placement (figure 2).

    Figure 2: X-ray alignment with no distortion
    Figure 2: X-ray alignment with no distortion

    By utilizing the Sniper X-Ray in combination with a conventional film/sensor holder, the implant surgeon can obtain consistent and accurate radiographs, resulting in greater measurement precision. This tool significantly improves the accuracy of intraoperative radiographs, allowing for more precise reevaluation during the dental implant surgical procedure (figure 3).

    Figure 3: Appropriate beam alignment
    Figure 3: Appropriate beam alignment

    The guide pins come in a variety of osteotomy sizes, allowing the user to take serial radiograph films during the procedure if needed (figure 4). This system consists of a base that attaches to the radiographic film holder. The base can be fixed or inserted on both sides of the film holder, allowing for a secure and stable attachment of the Sniper X-Ray tool (figures 5 and 5a). Assembly and disassembly are easy, and the system can be sterilized.

    Figure 4: Sniper X-Ray guide pins in a variety of osteotomy sizes
    Figure 4: Sniper X-Ray guide pins in a variety of osteotomy sizes
    Figure 5: Sniper X-Ray System base attaches to radiographic film holder
    Figure 5: Sniper X-Ray System base attaches to radiographic film holder
    Figure 5a: Stable attachment of Sniper X-Ray tool
    Figure 5a: Stable attachment of Sniper X-Ray tool

    Appropriate alignment of the x-ray beam is a critical factor in obtaining clear and accurate radiographic images, reducing distortion, and improving diagnostic quality during dental implant osteotomy preparation. When diagnostic radiographic data transfer is accurate, the dental implant has a higher probability of being placed appropriately (figures 6 and 6a).

    Figure 6: Using the Sniper X-Ray System to accurately place a dental implant
    Figure 6: Using the Sniper X-Ray System to accurately place a dental implant
    Figure 6a: Use of the Sniper X-Ray System assures accurate implant placement
    Figure 6a: Use of the Sniper X-Ray System assures accurate implant placement

    Watch this video to see how this system is used during dental implant surgery.

    Disclosure: Dr. Arguelles is the inventor and owner of the Sniper X-Ray System.
